HXY-A7  氣脹救生衣

適用范圍

適用于船舶

認可標準

1974年《國際海上人命安全公約》及修正案

MSC.48(66)《國際救生設備規則》及修正案

MSC.81(70)《經修正的救生設備試驗建議》

產品技術參數

形式：雙氣囊雙氣室

氣室材料： TPU

CO2 氣瓶重量：2*33g

充氣時間：≤5S

使用環境溫度： -30℃~+65℃

浮力：≥150N

浮力損失：≤5%

適合身高：≥155CM

適合體重：≥43KG

配件：口哨、伙伴繩和提拉襻

HXY-A7  Inflatable  Lifejacket

The Scope Of Application

Applicable to ships

Approval  Standard

International Convention for the Safety ofLife at Sea,1974,as Amended                              MSC.48(66)Internaional Life-saving Appliance Code,as Amended

MSC.81(70)Revised Recommendation on Testing of Life-saving Appliances,as Amended

Product Specifications

Type:Two airbag Two chambers

Compartment   Material:TPU

Co2   Cylinder   weight:2*33g

Inflation        time:≤5S

Usage  environment temperature:-30℃~+65℃

Buoyancy:≥150N

Buoyancy    Loss:≤5%

Fit   for   height:≥155CM

Fit   for   weight:≥43KG

Accessories:whistle 、buddy line and lifting becket

1. 確認救生衣的前后，先把救生衣掛單肩上，手臂先穿過一側帶子。

2.然后手臂再穿過另外一側。

3.系好扣帶并調整帶子到合適的寬度。

4.直接入水：溶解栓遇水自動發生溶解反應使膨脹裝置動作刺穿氣往氣囊中充入二氧化碳氣體。

充氣入水：右手用力下拉手動拉繩，使膨脹裝置動作刺穿氣瓶往氣囊中充入二氧化碳氣體。

5.如果浮力不夠的情況下，左手下拉手動繩打開第二個氣囊，或從吹氣管中往氣囊里吹入氣體。

1.Distinguish the obverse and the reverse sides of life jacket.Hang the life jacket in single shoulder,one arm goes through one side of strap.

2.Then pass  the  other  arm  through  the  other  strap.

3.Fasten  straps  and  adjust  straps  to  the  proper position.

4.Direct use:the  disovling plug  disolves  automatically when it meets with water,which makes the  expansion  device  act pierce the  gas  cylinder

andfll the air bag with carbon dioxide.Use after Inflation:pull sharply on the cord with your right handwhich makes the expansion device act to   pierce the gas cylinder andfill the air bag with carbon dioxide.

5.In case of insufficient buovancy.Pull on the cord with your left hand to oen the second airbag,or blow air into airbag through air tube.
